Thickness Gauge(hot end)
The on-line glass thickness gauge system which is developed by our company can be installed in A zone of lehr or the narrow section of the tin bath. The inside measuremrnt mechanism is protected by circulating water and N2. Measurement layer is coated with thermal insulation material, so the influence to tin bath temperature can be reduced.
Classification:
Thermal thickness gauge
key words： Thickness Gauge(hot end)
Product Details
The on-line glass thickness gauge system which is developed by our company can be installed in A zone of lehr or the narrow section of the tin bath. The inside measuremrnt mechanism is protected by circulating water and N2. Measurement layer is coated with thermal insulation material, so the influence to tin bath temperature can be reduced.
Thickness Gauge Equipment(hot end) Specifications
|
Specifications |
Parameter |
|
Thickness Measurement Range |
1.5-30mm(0.8-8mm) |
|
Accuracy |
±0.1%F.S. |
|
Resolution |
0.001mm |
|
Width Measurement Accuracy |
±10mm |
|
Tin Level Measurement Resolution |
0.1mm |
|
Measuring Bridge Ambient Temp |
＜800℃ |
|
Measurement Cycle |
＜60S |
|
Working Distance |
60～80mm |
